Hot selling digital echo karaoke mixer with 99DSP broadcast mixer for wholesale
6/8/10/12 channels for choise
14/8 balanced line input,sufficient dynamic headroom
6 Technical novel microphone preamplifier with a separate high-level comparable to pre-amplifier
Each channel is equipped with three auxiliary send:a prfader for monitoring;a pre/post fader ,or in monitoringthe effect and external audio equipment
Mono are effective with the semi-parametric mid 3-band EQ the sound can become warm and very musical
9 graphic equalizer allows stereo main mix and monitor the frequency of mixing more accurate calibration
Revolutionary FBQ may produce immediate feedback shows that the frequency of
Buit-in 24-bit stereo digital effect processor has 99 preset sounding VIRTULIZER
People marvel of 3D XPQ srereo surround effect allows a more vivid sound waves
| Frequency response: | |
| Mic/Line input to any output | 14Hz to 25KHz +0dB/-1dB |
| THD+N: | |
| <0.02% 20Hz to 20 KHz Mic to left/right output | 0Hz to 80KHz BW |
| <0.005% Typical | 22Hz to 22KHz BW |
| <0.0007% Mic pre-amp Distorti | |
| S/N: | |
| Mic input E.I.N.(maximum gain) | -127dBu(150Ω source) |
| Aux,Mix and masters(@0dB,faders down) | <-85dBu |
| Crosstalk(@1KHz): | |
| Channel Mute | >90dB |
| Fader cuo-off(rel+10 mark) | >90dB |
| Aux send pots offness | >86dB |
| Input and output level: | |
| Mic input | +15dBu max |
| Line input | +30dBu max |
| Stereo input | +30dBu max |
| Mix output | +20dBu max |
| Headphones(@150Ω) | 300mW |
| input and output level: | |
| Mic input | 2KΩ |
| Stereo input | 65KΩ(stereo),35KΩ(mono) |
| Outputs | 150KΩ(balanced),75KΩ(unbalanced) |
| Line input | 10KΩ |
